Features

• Aerator type: Standard aerator
• Connection form: Copper connection pipes
• Washing machine valve type: Mechanical washing machine valve
• Lever/Handle Type: Single operating lever/handle, Eco function, Hot/Cold symbols
• Mechanical parts: ø 40 mm adjustment part
• Special features: 3S-Installation mounting system
• Spout type: Swivel spout, Swivel angle limitation option
• Color: Chrome
• Temperature controls: Temperature and flow limitation option

Flow attributes

• Eco flow rate 300 kPa: 0.15 l/s
• Flow rate 300 kPa: 0.29 l/s
• Pressure loss with flow (0.2 l/s): 145 kPa

Technical features

• Backflow protection (EN1717): AA
• Connection size: Ø 10 mm
• Hot water max. +80°C
• Material: Brass
• Reach: 214 mm
• Operating pressure: 50 - 1000 kPa

Articles

• EN standard: EN 817
• Sound class: I (ISO 3822)

Approvals and Declarations

• STF certificate: EUFI29-20000935-TH1

Responsibility

• EPD module A1 (kg CO2 eq.): 9.37
• EPD module A1-A3 (kg CO2 eq.): 13.93
• EPD module A2 (kg CO2 eq.): 0.45
• EPD module A3 (kg CO2 eq.): 4.12
• EPD module A4 (kg CO2 eq.): 0.28
• EPD module B7 (kg CO2 eq.): 3546.00
• EPD module C2 (kg CO2 eq.): 0.02
• EPD module C3 (kg CO2 eq.): 0.02
• EPD module C4 (kg CO2 eq.): 0.42
• EPD module D (kg CO2 eq.): -7.87
