Characteristics

• Nozzle type: Standard nozzle
• Connection type: Direct connection to connectors, Internal thread
• Type of changer: Reversible changer, Integrated in the volume adjustment handle
• Lever/Handle type: Heat control handle, Quantity control handle
• Mechanical parts: Debris strainers, One-way valves, Thermostatic control part
• Shower parts: Eco-flow function
• Type of spout: Fixed spout
• Color: Chrome
• Temperature adjustments: Safety knob at 38°C

Current attributes

• Eco flow at 300 kPa: 0.16 l/s
• Flow at 300 kPa: 0.23 l/s
• Pressure drop when flowing (0.2 l/s): 230 kPa

Technical characteristics

• Back suction protection (EN1717): EB
• Connection size: G1/2
• Hot water max. +80°C
• Installation width: 150 mm
• Material: Brass
• Operating pressure: 100 to 1000 kPa

Articles

• EN standard: EN 1111
• Sound class: I (ISO 3822)

Approvals and Declarations

• STF certificate: EUFI29-22005199-TH

Responsibility

• EPD module A1 (kg CO2 eq.): 7.98
• EPD module A1-A3 (kg CO2 eq.): 9.26
• EPD module A2 (kg CO2 eq.): 0.37
• EPD module A3 (kg CO2 eq.): 0.92
• EPD module A4 (kg CO2 eq.): 0.33
• EPD module B7 (kg CO2 eq.): 20256.00
• EPD module C2 (kg CO2 eq.): 0.02
• EPD module C3 (kg CO2 eq.): 0.02
• EPD module C4 (kg CO2 eq.): 0.66
• EPD module D (kg CO2 eq.): -5.88
